Scaffolding Cuplock System
1. Comfortable to stand on. The ends of up to four members can be connected in a single locking operation without the need for nuts, bolts, or wedges thanks to a straightforward locking cup at each node point on the standards.
2. Flexible. Ideal for formwork support or access.
3. An up-to-date, proven design with safety add-ons. Cuplock System satisfies the standards of the various statutory agencies and has a track record of demonstrated performance on a large number of sites.
4. Horizontals fastened quickly. With the top cup’s powerful clamping action, only four horizontals can be fastened at once, rigidifying the joint.
5. Time and labor are saved during the quick, fast, and solid erection and disassembly.
6. Widely and adaptably used in maintenance, demolition, and construction projects for any kind of construction, including curved and straight ones.
7. High load bearing capacity but lightweight design.
8. Low upkeep.
The pipe is of Hot Rolled Steel as per BS-1139 Standard, The Jack Nut of SG Iron Castings. Made from pipe of 38mm OD X 650mm Height.
The Pipe of Hot Rolled Steel as per BS-1139 Standard. Made from Pipe of 48mm OD, 4mm or 3.2mm.
The Pipe of Hot Rolled Steel as per BS-1139 Standard.Made from Pipe of 48 mm OD, 4 mm or 3.2 mm
The Pipe of Hot Rolled Steel as per BS-1139 Standard.Made from Pipe of 48mm OD, 4mm or 3.2mm
The Pipe of Hot Rolled Steel as per BS-1139 Standard .Made from Pipe of 38mm OD X 4mm and height is 300mm, Available with a pair of Bolts and Nuts.
The Pipe of Hot Rolled Steel as per BS-1139 Standard. Made from Pipe of 38mm X 4mm and Height of 300mm and a washer is welded at the center.
The Pipe of Hot Rolled Steel as per BS-1139 Standard. Made from 48.3mm X 3.2mm pipe.
Hot dipped, galvanized, painted ladder beam made of pipe of diameter 48.3 mm with thickness 3mm to 4 mm.Available in 6 m.
The Pipe of Hot Rolled Steel as per BS-1139 Standard.Made from 48.3mm X 3.2mm pipe.
The Pipe of Hot Rolled Steel as per BS-1139 Standard. Made from 38mm X 4mm pipe, 650mm length.
CThe Pipe of Hot Rolled Steel as per BS-1139 Standard. Made from 38mm X 4mm pipe, 650mm length.
The Pipe of Hot Rolled Steel as per BS-1139 Standard. Made from 38mm X 4mm pipe, 100mm length.
The Pipe of Hot Rolled Steel as per BS-1139 Standard. Made from 48.3mm X 3.2mm pipe, the height is 100mm.
The Main component of the Decking System, used over each standard with a socket adoptor. Made from Sheeted components, The Critical Height is 70mm.
The Primary Beam that is used with the Drop Head to form the Decking System. Made from Sheeted components, used with Drop head, the sheet thickness is 3mm.
Quaddream is a premier manufacturer of Cuplock Scaffolding in UAE, offering a comprehensive range of Cuplock accessories. As a leading Cuplock Scaffolding provider in Dubai, UAE, we supply standard Cuplock, ledger, bevel and brackets, adjustable leveling jack and U head, Cuplock steel plate, base plate, and more.
As an ISO-certified Cuplock Scaffolding manufacturer, Quaddream guarantees the quality and safety of all Cuplock Scaffolding accessories. Our Cuplock raw materials, including Cuplock tubes, Cuplock cups, and Ledger blades, undergo rigorous testing and qualification before production. Our welding lines are tested according to ISO certification standards.
Regular system scaffold model checks are performed to ensure that all Cuplock Scaffolding components are well-matched and compatible. Quaddream also provides detailed installation instructions for Cuplock Scaffolding Systems, ensuring safe and efficient assembly.
With extensive manufacturing and exporting experience, Quaddream supplies Cuplock Scaffolding Accessories of any size throughout the UAE. Contact us with your Cuplock Scaffolding construction requirements for a favorable price and top-quality service.
Quaddream is your trusted partner for Cuplock Scaffolding in UAE.
Cuplock Scaffolding is a versatile and efficient scaffolding system known for its ease of use and high performance. The system features a unique locking cup at each node point, allowing up to four members to connect in a single locking operation without the need for nuts, bolts, or wedges. This design makes Cuplock Scaffolding comfortable to stand on and ensures quick and secure assembly. The flexibility of Cuplock Scaffolding makes it ideal for formwork support and access in various construction projects.
One of the key advantages of Cuplock Scaffolding is its up-to-date, proven design with safety add-ons, meeting the standards of statutory agencies. The powerful clamping action of the top cup allows for rapid fastening of horizontals, rigidifying the joint and enhancing stability. Cuplock Scaffolding significantly saves time and labor during erection and disassembly due to its quick and solid setup process.
Cuplock Scaffolding is widely used in maintenance, demolition, and construction projects, suitable for both curved and straight structures. Despite its high load-bearing capacity, the system remains lightweight and requires low upkeep. Cuplock Scaffolding’s combination of strength, flexibility, and efficiency makes it an indispensable tool in the construction industry.
Quaddream Scaffolding Contracting LLC is one of the leading suppliers of scaffoldings since 2012
